Emerson KL2101X1-BB1 12P8775X052 DeltaV CHARM I/O Card 2 (CIOC2)

SKU KL2101X1-BB1

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: Emerson

  • Product No.: KL2101X1-BB1

  • Country of origin:United States

  • Product Type: I/O Cards

  • Payment: T/T, Western Union

  • Weight: 500g

  • Dimensions: 160 mm x 120 mm x 40 mm (H x W x D)

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The Emerson KL2101X1-BB1 DeltaV CHARM I/O Card 2 (CIOC2) is a specialized I/O processing interface designed for the DeltaV Electronic Marshalling Digital Automation System. The KL2101X1-BB1 provides power conversion and signal management within the CHARM I/O Subsystem, facilitating input and output processing across process automation networks.

Features

  • Part of the DeltaV Electronic Marshalling Digital Automation System (CHARM I/O Subsystem)
  • Converts 24 VDC input power to 6.3 VDC output power
  • Designed for operation in rated hazardous locations
  • Maintenance-free design requiring no disassembly or routine calibration

Applications

  • DeltaV Electronic Marshalling CHARM I/O Subsystems
  • Process automation and digital control system hardware architectures
  • Zone 2 and Class I, Division 2 hazardous area installations

Technical Specifications

Parameter Value
Manufacturer Emerson
Model KL2101X1-BB1
Card Type CHARM I/O Card 2 (CIOC2)
System Compatibility DeltaV Electronic Marshalling Digital Automation System
Input Power 24 VDC at 2 A Max
Output Power 6.3 VDC at 3.25 A
Ambient Temperature -40 degC to +70 degC
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2 Hz; 0.7 g from 13.2 to 150 Hz
Airborne Contaminants ISA-S71.04-1985 Airborne Contaminants Class G3
Relative Humidity 5 to 95% non-condensing

Installation Guidelines

  • Do not remove or insert this unit with system power energized unless the area is known to be non-hazardous.
  • Follow installation instructions detailed in document 12P5403 ("DeltaV Electronic Marshalling Digital Automation System (CHARM I/O Subsystem) Zone 2 Installation Instructions") and the "DeltaV S-Series and CHARMS Hardware Installation" manual.
  • Ensure proper environmental protection matching ISA-S71.04-1985 Class G3 standards for airborne contaminants.

Compliance and Certifications

  • ATEX: II 3G Ex ec IIC Gc (FM19ATEX0173U)
  • IECEx: IECEx FMG 19.0019U
  • UKEX: FM21UKEX0017U
  • FM / cFM Approved: Class I, Division 2, Groups A, B, C, D; Class I, Zone 2 AEx/Ex ec IIC Gc (FM17CA0145U, FM17US0286U)
  • CE
  • CSA: CA CLR87634 US

FAQ

What is the Emerson KL2101X1-BB1 used for?
The Emerson KL2101X1-BB1 is a CHARM I/O Card 2 (CIOC2) used in the DeltaV Electronic Marshalling Digital Automation System to manage and power I/O subsystems.

Which automation system is the CIOC2 card compatible with?
The card is designed specifically for the Emerson DeltaV system, operating within the CHARM I/O Subsystem architecture.

What are the power specifications for the KL2101X1-BB1?
The card requires an input power of 24 VDC at 2 A Max and provides an output power of 6.3 VDC at 3.25 A.

Can the KL2101X1-BB1 be removed or inserted while power is energized?
The unit cannot be removed or inserted with system power energized unless the installation area is verified to be non-hazardous.
